What is a header tank for central heating

The header tank, otherwise known as the feed and expansion tank or cistern, is an essential part of an open vented central heating system with a regular boiler. The role of the header tank is to supply water to the central heating system and also maintain the level of water, which expands when heated.

What is the purpose of a header tank?

The header tank is used to fill the heating system and accommodate the expansion of water during the heating cycle. It has an overflow pipe running to outside, a mains water supply connecting to the tank via a ball valve used to fill the system and a cold feed pipe* and an open vent pipe*.

Does a combi boiler have a header tank?

However, unlike a conventional boiler, it doesn’t require a header, or cold feed, tank in the loft. A system boiler takes water from the mains supply, like a combi boiler, and heats it in the heat exchanger. … So, when you’re choosing a cylinder for your system boiler, you need to choose the right size.

What is a header tank system?

marine. A liquid storage tank which maintains a head or gravity pressure in the system. It acts as an expansion tank and also supplies liquid to make up for system losses.

Do I need a header tank?

Basically though, unvented hot water systems (also known as sealed systems) operate under mains pressure, and take advantage of a bubble of air in the cylinder or a separate expansion vessel to allow expansion of the hot water. For this reason no cold water header tank is necessary.

Why is header tank overflowing?

There are many reasons why the header tank is overflowing: Issues with pump over run. Faulty coil in the hot water tank. Ball valve needs repairing or replacing.

Should header tank be covered?

An insulating jacket prevents the cold water in the header tank from freezing up, and this also helps to stop pipes from freezing. … Header tank insulation is recommended if you’re having your pipes lagged for winter.

How much water should be in central heating header tank?

This is so that the water in the central heating system has the space to expand when heated. The cistern must be able to accommodate the expansion of the water by approximately 4% of its original volume. The elevated water level must be at least 25 mm / 1 inch below the overflow.

Can I use isolation valves on central heating?

Central heating isolation valve are often refered to as butterfly valves. … These isolation valves are suitable for Heating Applications Only.

What are header tanks made of?

Header tanks are commonly made from plastic, but can be made from a range of materials. Metal header tanks are better suited for use in systems where the water can become very hot due to the uncontrollable nature of the heat source.

Article first time published on

How do I clean my central heating header tank?

1. Turn water off, and drain tank either by pumping the water out, or draining down the heating system just enough to empty the tank.
2. Clean all the sludge.
3. First put inhibitor in the tank, then fill the rest with water.

How do I stop my hot water cylinder from overflowing?

Find the PTRV valve on the side of the cylinder near the top or bottom, then lift the silver lever three or four times to open, close and clear any blockages. If the water flow comes to a stop then your problem is solved. But if it keeps running then you probably need to replace the valve.

Are combi boilers being phased out?

There are no plans to phase out gas boilers in existing homes. That said, the government may encourage more of us to ditch gas in favour of alternatives. … And UK homeowners would have to replace their boiler with a low-carbon alternative.

Does a combi boiler have to be on an outside wall?

Your boiler should be installed inside a building and can be fitted to any suitable wall strong enough to take its weight when full of water. The boiler’s flue must be able to pass to the outside, either through an outside wall or through the roof.

Why does my combi boiler run out of hot water?

If the boiler pressure is too high or too low, this can result in your combi boiler not producing hot water. … This should release pressure. If this doesn’t work, it may be possible that your boiler has a broken part, and you’ll need to consult an engineer. Boiler leaks can also cause low pressure.

Can you run an electric shower from a header tank?

No go man, any electric shower needs to be mains fed. Connect it to a tank and the low pressure light will light, plus you will invalidate the warranty.

Why do I have two header tanks?

If you are not sure why there are two water tanks in your loft, it is probably because the property has (or used to have) a vented central heating system. … The smaller tank is a header tank which is there to fill the heating system and provide extra space for the water to expand when heated.

Why is hot water coming out of my overflow pipe?

Hot water systems It’s also called the relief valve. Water expands when heated, pressure builds up in the tank and is released through the overflow pipe. So water dripping or running from the valve can be a sign of a normal, functioning system.

Should attic water tanks be covered?

The tank must be insulated and fitted with a dust proof lid. Pipes must be supported and lagged. There may be very good, and sometimes excessive, water pressure in the area resulting in more noise on filling. Reducing the flow into the house from the main stop cock outside might help.

Why does my hot water tank keep filling up?

Reasons Why Your Water Heater is Constantly Running Your water heater might have insufficient insulation – If the water heater is not properly insulated, it will be unable to maintain the water temperature. If this is the issue you can purchase an insulating wrap at any local hardware store.

Why does my expansion tank keep filling up?

Not Enough Air in Diaphragm Tank The most common expansion tank problem in a diaphragm tank is losing small amounts of air through the valve. … If the tank does not hold its air pressure after you complete this fix or it fills with excess water, you may need to replace the diaphragm.

Is a leaking overflow pipe an emergency?

But the valve only flows when there is a problem in the system. So, if you see this valve leaking, you should immediately take notice. The pipe might leak because of excessive pressure to the system or because of issues with the pressure valve. In both cases, it is highly advised to call professionals for service.

Why is hot water feeding back into header tank?

Another frequent cause is a blockage where the feed / vent pipes from / to the F&E tank join the main pipework. That causes hot water to go up the vent into the small tank whence it is dragged back into the system again via the feed.

Why is my heating system pumping over?

Pumping over refers to a symptom of an improperly configured central heating system in which water is discharged into the feed and expansion cistern via the expansion pipe while the pump is running. The cause is usually either: … The pump’s speed is too high.

Can I cut a central heating pipe without draining the system?

Just undid the pipes. I’d suggest you turn off all your radiators and then drain just the pipework. That way you can keep the bulk of the water and inhibitor trapped in the rads and you’ll only have to refill the pipework. Then you can safely cut and cap without worrying about ice plugs giving way.

What is lockshield valve?

Lockshield valves are the covered valves on a radiator, usually by a plastic cap which prevents them from being accidently altered. Once this has been temporarily removed, lockshield radiator valves can be adjusted by turning the spindle to control how much water stays in or flows out of the radiator.

How do I isolate my central heating system?

1. Switch off the boiler. …
2. Shut off the water intake valve. …
3. Locate the drain-off valve and attach a hosepipe or place a bucket under it. …
4. Drain the radiators. …
5. Open the bleed valves to speed up the process. …
6. Complete the drainage process.

Why does my cold water tank keep overflowing?

Typical cause – a faulty ball valve The most common reason for a cold water tank to overflow is a faulty ball valve. … As the water level in the cistern rises, the float pushes a washer onto the valve seating – a plastic nozzle inside the valve body. This stops the flow of water into the cistern.

Where is the ball valve and expansion cistern?

The cistern is usually found in the loft, the small tank. If dry then the cistern will need to be refilled. To refill the cistern simply tap the ball valve, the water should start to fill the cistern and stop when there is just enough water to float the ball valve.

What happens when expansion tank fails?

Oftenthe diaphragm dividing the two systems will fail, causing the two systems to become one. When this happens, the expansion tank turns into a “dead leg” that will eventually cause damage and premature failure to your water heater.

What is the major advantage of a diaphragm expansion tank?

The rubber diaphragm in modern expansion tanks prevents this undesired transfer of air, and helps maintain low levels of oxygen within the pipes, reducing corrosion in the system.
